Toyota hiace is one of the best suitable van to make ambulances. Toyota HI Ace comes in new shape with 3.5 liter petrol engine in manual and automatic transmission. Vehicle is available with delivery van option and passenger van option also to convert to ambulances. 6 cylinder capacity engine make this vehicle is very suitable in fast moving and all terrain applications and the inside space make this vehicle a perfect choice for the paramedics to accommodate ICU equipped medical equipment. AutoZone is one of the largest ambulance manufacturer in Dubai – UAE who make HIace high roof ambulances more in numbers and export to many countries.
Toyota HIace ambulances comes with a very wide medical cabinet to accommodate the medical equipment and other consumables. Oxygen cylinders are fixed in the same cabinet with proper fixation brackets. Oxygen cylinders are connected to the wall mounted outlets through oxygen pipes which is anti-static and high pressure type. The squad bench can capable of sitting 3 peoples and secure with safety belts. Squad bench have the storage option with high strength gas spring which allow to storage the foldable stretcher and other needed materials. Toyota HIace high roof ambulance have the advanced medical equipment on board like defibrillator, patient monitor, ECG machines, emergency transport ventilator, and many other equipment for life saving .
Patient transport system globally need more user friendly vehicles which makes paramedics to operate quickly and efficiently to reach in the accident spot and carry the patient. Toyota HI ace is the model which proven its easiness with driver and high standards of performance from long years. AutoZone as a largest converters of vehicles promise to the end users your Toyota vehicle ambulances are best in applications. Considering the after sales and spare parts availability in every country large fleet of ambulances always make this choice easily.
- MAKE TOYOTA
- MODEL NAME HIACE
- GRADE HIACE D/VAN HR DX
- MODEL CODE GRH320L-HBFDHV
- BODY TYPE VAN
- DIMENSIONS Lx Wx H mm 5915x1950x2280
- WHEEL BASE mm 3860mm
- GROUND CLEARANCE mm 180
- MIN. TURNING RADIUS(M) 6.4
- KERB WEIGHT (Kgs) 2280-2290
- GROSS VEHICLE WEIGHT (Kgs) 3400
- FUEL TANK CAPACITY Ltrs. 70
- DISPLACEMENT cc 3456
- HP (SAE Net) / RPM 268
- TORQUE (SAE Net) KgM /RPM 34.9
- TYPE 6 CYLINDER
- FUEL SYSTEM D-4S
- FUEL TYPE GASOLINE
- CATALYTIC CONVERTER WITH
- EMISSION CERT. EURO 4
- T/M 6 M/T
- TIRE SIZE 215/70R 16
- WHEEL CAP FULL – TYPE 1
- POWER/TILT WITH/WITH
- TELESCOPIC WITH
- FRONT/REAR V. DISC/ V.DISC
- FRONT MCPHERSON
- REAR LEAF SPRING
- SEAT RR. SEAT FR. SEAT BELT 3PELRx2 ( D+P – PT + FL) + 2PNRx1
- SEAT BELT WITHOUT
- HEAD REST WITHOUT
- FUEL LID OPENER WITH
- INNER REARVIEW MIRROR DAY / NIGHT
- LIGHT CONTROL SYSTEM SENSOR ONLY
- REAR LEFT SIDE GLASS PANEL
- REAR QUARTER LEFT GLASS PANEL
- REAR QUARTER RIGHT GLASS PANEL
- REAR RIGHT SIDE GLASS PANEL
- SEAT MATERIAL FABRIC
- SEATING CAPACITY 3
- SUN VISOR D+P (PVC)
- BUMPER FR. & RR. BLACK
- DOOR HANDLES BLACK
- FRONT GRILLE SILVER
- HEADLAMPS HALOGEN
- HIGH MOUNT STOP LAMP WITH (LED)
- OUTER REAR VIEW MIRROR
- COLOUR KEYED + BLACK, POWER,
- POWER RETRACTABLE, TURN SIGNALS ,W/UNDER VIEW MIRROR
- WINDSHIELD GLASS REINFORCED,UV CUT GREEN
- PVC Medical Cabinet for equipments and medicines
- Air Conditioning Unit for patient’s cabinet
- Bulk Head with Sliding Glass Window
- Attendant Seat tip-up bench with under seat storage area
- Flooring with marine plywood and Vinyl coating
- Power Inverter
- Electric panel board with fuses
- Electrical Outlets-12V DC
- Electrical Outlet- 220V AC
- LED Patient Cabinet Lights
- Flood light at rear of ambulance
- LED Multi flashing Roof Light Bar with siren and Speaker
- Rear Beacon Lights
- Front bumper lights red/blue
- Roof type ventilation fan
- Frosted Side Glass.
- Triangle Sign
- Emergency window hammer
- Fire extinguisher
- Livery, Designing of Ambulance body
- All Kind of Warning Stickers inside ambulance
MEDICAL EQUIPMENT
- Automatic Loading stretcher
- folding stretcher
- Oxygen Cylinder with valve
- Medical Regulator with flow meter and humidifier
- Oxygen Mask
- Oxygen outlet with piping and tubing
- First AID Box
- Portable suction unit
- Stethoscope
- Sphygmomanometer
- Syringes 10 mm,5 mm,3 mm
- Neck Collar
- Face Masks
- Roof Mounted IV Hook
- Sharp Container
OPTIONAL EQUIPMENT
- Portable ventilator
- Patient Monitor
- AED automated external defibrillator
- Stretcher platform
- Immobilization devices
- “D” Size Oxygen Cylinder
- Traction Splint Kit
- infusion pump
- syringe pump
- ECG Machine
