AR
FR
Category
Model
Drive Train
Transmission
Fuel
- Torque: 71.38kg /1600-2600
-
Output (hp/rpm): 302/4000
-
Dimensions(mm): L 5015 x W 1980 x H 1890
-
Wheel base : 2850mm
-
Gross vehicle weight : 3230 kg
-
Ground clearance : 235mm
- Cruise control
- Anti-theft system with security horn
- Power steering
- Wireless charger
- Back monitor
- Airbag
- Windshield glass
- Aero package
- Sensors: 4 Front side and 4 Rear side
- Roof rail
- Towing hitch
- Sunroof
Standard Armoring spec
- Standard & Luxury options available
- All opaque material around passenger area retrofitted with ballistic steel
- Roof And floor with angular protection
- Additional areas of armoring include the fuel tank, battery and computer module
- Original glass is replaced with laboratory-tested multilayered ballistic glass
- P.A./multi-siren system and LED strobe lights, per client’s specifications
- Reinforced door hinges to support additional weight of the armor
- Patented designed armoring for the firewall and the wheel wells
- A complete set of high-grade run-flat devices are installed
- All door and window openings feature overlapped steel
- Rear ballistic steel partition with overlap and door
- Additional protection for the floor and the radiator
- Further options upon request
Armored in accordance to level B6 CEN pr EN 1063 / EN 1522 / 1523
Ballistic Levels
| Class | Weapon | nCaliber | Type | Weight (g) | Range (m) | Velocity (m/s) | Impact Energy | Shots |
| BR1 | Handgun/Rifle | .22 LR | LB/RN | 2.6 ± 0.1 | 10.00 ± 0.5 | 360 ± 10 | 170 J | 3 |
| BR2 | Handgun | 9x19mm Parabellum | FJ/RN/SC | 8.0 ± 0.1 | 5.00 ± 0.5 | 400 ± 10 | 640 J | 3 |
| BR3 | Handgun | .357 Magnum | FJ/CB/SC | 10.2 ± 0.1 | 5.00 ± 0.5 | 430 ± 10 | 940 J | 3 |
| BR4 | Handgun | .44 Magnum | FJ/FN/SC | 15.6 ± 0.1 | 5.00 ± 0.5 | 440 ± 10 | 1510 J | 3 |
| BR5 | Rifle | 5.56x45mm NATO | FJ/PB/SCP | 4.0 ± 0.1 | 10.00 ± 0.5 | 950 ± 10 | 1800 J | 3 |
| BR6 | Rifle | 7.62x51mm NATO | FJ/PB/SC | 9.5 ± 0.1 | 10.00 ± 0.5 | 830 ± 10 | 3270 J | 3 |
| BR7 | Rifle | 7.62x51mm NATO | FJ/PB/HC | 9.8 ± 0.1 | 10.00 ± 0.5 | 820 ± 10 | 3290 J | 3 |
