Golf Cart Ambulance

Category :Ambulance
Model : Autozone
Origin : China
Drive Train :2WD
Drive : LHD
Transmission : Auto

Get a Quote

Share

Golf Cart Ambulance is a small, electric-powered vehicle that has been converted for use as an ambulance. It is typically used for transporting patients within a hospital campus or in recreational areas where larger emergency vehicles may have difficulty navigating. Golf Cart Ambulances are designed to be small, lightweight and maneuverable, making them ideal for navigating tight spaces and congested areas. They are equipped with basic medical equipment and supplies to provide basic life support to patients while in transit. However, they are not intended for use in serious medical emergencies and should not be relied upon as a substitute for a full-sized ambulance.

  • Battery : 6PCSxT875(145Ah@5hr rate)
  • Motor: 3.8KW  motor
  • Controller: Curtis 1268 (400A@2minutes)
  • Overall dimensions (mm): 3110X1180X1890
  • Min. ground clearance (mm): 120
  • Wheelbase (mm): 2450
  • Front wheel tread (mm): 855
  • Rear wheel tread (mm): 975
  • Steering system: Single-stage rack and pinion steering system, automatic rocker compensating function
  • Brake system: Mechanical brake
  • Accelerator: Stepless speed change
  • Suspension system: Front and rear plate spring + cylinder hydraulic shock absorber
  • Driving mode: Rear axle two stage deceleration, motor direct driving
  • Rear axle: Integrated, Gear ratio 12.76:1
  • Large Seats:
  •     1) backrest and cushion     Rebond seat + artificial leather
  •      2) armrest   Formed
  •      3) plastic seat bottom        Last row of seat
  • Floor: rubber
  • Center storage basket Large volume
  • Golf bag holder
  • Dashboard in black plastic
  • forward/reverse switch, battery capacity indicator, ignition key
  • Beverage holders
  • 4 cups drink holders
  • Glove box
  • Side trim: Aluminum
  • Scorecard holder: on steering wheel
  • Frame: Welded steel framework with phosphate+electro-coating treatment
  • Body: PP plastic front body + PP plastic rear body
  • Roof: Fibreglass
  • Windshield: one-piece Organic glass
  • Towing bracket : on front of golf car
  • Lighting system and horn       2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
  • Reversing alarm
  • Charger: input 110V-240V~50Hz-60Hz, output 36V/48V, 25A
  • Automatic Loading stretcher
  • Portable Oxygen Cylinder with valve
  • First AID Box
  • Stethoscope
  • Power Inverter
  • Electrical Outlets-12V DC
  • Electrical Outlet- 220V AC
  • LED Patient Cabinet Lights
  • Flood light at rear of ambulance
  • LED Multi flashing Roof Light Bar with siren and Speaker
  • Rear Beacon Lights
  • Front bumper lights red/blue
  • Fire extinguisher
  • Livery, Designing of Ambulance body
  • All Kind of Warning Stickers inside ambulance
